Product Description:

Lab Fume Hood With Sink provide a safe and effective method for controlling hazardous fumes and vapors in laboratories. This product features a horizontal structure made of stainless steel with a noise level of ≤60dB, powered by 220V voltage. It is also customizable in terms of size so that it fits your specific needs. Not only is it reliable and durable, but it also provides maximum protection for your laboratory environment. Chemical Fume Hoods are ideal for controlling hazardous fumes and vapors, and protecting your laboratory from potential dangers. With its superior performance and excellent safety features, Chemical Fume Hoods are the perfect solution for your laboratory.

Features:

• Product Name: Lab Fume Hood With Sink
• Lighting: LED
• Noise: ≤60dB
• Power: 50W
• Airflow: 400m³/h
• Material: Stainless Steel

Technical Parameters:

Applications:

Lab Fume Hood With Sink produced by SUCLAB (Model Number: HZJ011) are certified by ISO9001, ISO14001, and are built to last. Manufactured in CHINA, this Chemical Fume Hood requires a minimum order quantity of 1 STE. Price is negotiable and the package is Export Plywood Package. Delivery time is 15 Days, and accepted payment terms include T/T, D/A, L/C, D/P, and MoneyGram. With a supply ability of 10000 Sets /Month, buyers can rest assured of the availability of this Chemical Fume Hood. The product is also guaranteed for 1 Year, and has a voltage of 220V, an airflow of 400m³/h, an installation type of Wall Mounted, and a power of 50W.

Customization:

At SUCLAB, we provide customized Chemical Fume Hood service for our customers. Our Chemical Fume Hood has the following attributes:

• Brand Name: SUCLAB
• Model Number: HZJ011
• Place of Origin: CHINA
• Certification: ISO9001, ISO14001
• Minimum Order Quantity: 1 STE
• Price: Negotiation
• Packaging Details: Export Plywood Package
• Delivery Time: 15 Days
• Payment Terms: T/T, D/A, L/C, D/P, MoneyGram
• Supply Ability: 10000 Sets /Month
• Installation Type: Wall Mounted
• Voltage: 220V
• Structure: Horizontal
• Control System: Microcomputer
• Airflow: 400m³/h

Our Lab Fume Hood With Sink are designed to provide protection from hazardous gases and fumes in the laboratory. We guarantee that our Chemical Fume Hoods are of superior quality and design. We are committed to providing our customers with the best service and products.

Support and Services:

Chemical Fume Hoods are designed to provide a safe environment for laboratory personnel working with hazardous materials. The hoods are designed to capture fumes, vapors, and other hazardous substances, and direct them away from the work area.

At ABC Laboratories, we provide comprehensive technical support and service for our Chemical Fume Hoods. Our service engineers are trained in the installation and maintenance of these units, and can provide assistance with troubleshooting and repairs.

We also offer preventative maintenance, including regular checks and repairs to keep your Chemical Fume Hoods running at peak efficiency. Our service team can also advise on best practices for using the units, and can provide advice on the proper disposal of hazardous materials.

For any questions or assistance with your Chemical Fume Hoods, please contact our service team at 1-800-123-4567.

Product Description

Dimension	Length mm(L)		Width mm(W)	Height mm(H)	Total Height mm	Remark
1	1200		850	2350	2350
2	1500		850	2350	2350
3	1800		850	2350	2350
Notes: 1.Above size is our standard item. 2.Dimension can be customized upon customer’s request. 3.Built-in axial flow blower and⊄250mm exhaust duct included.
Housing		Using 8.0mm PP polypropylene plate welding production, after carving, bending the entire cabinet at one time, featured with strong anti-acid and alkali, corrosion resistance.
Inner shell		Using a new 8.0mm PP polypropylene plate welding production, with strong anti-acid and alkali, corrosion resistance characteristic, the inner side board can be fixed with water cock, gas cock. The back plate can be fixed with baffle, roof lighting and gas hood device.
Operational worktop		8.0mm PP polypropylene worktop, includes water fender, spray-proof, the table has a good performance of waterproof, anti-acid and alkali.
Baffle		8.0mm PP polypropylene board, resistant to strong acid and alkali. Installed in the back of the work space and above, including at least three pieces plates, so that the work space and the connection between the exhaust pipe to form a gas chamber, the polluted gas are exhausted completely, the baffle plate is attached to the cabinet with the clips, detachable.
Gas hood		PP material, with a strong corrosion resistance, rectangular opening at the bottom of the entrance, circular opening at the top
Fluorescent lamp		1 piece 30W light (waterproof, anti-corrosion, anti-oxidation)
Window sliding door		Movable vertical pull-up door, placed between the work space and the operator to protect the operator's safety, combined with the balance position, sliding doors can be stopped at any point of activity. a piece of tempered glass window on the adjustable door, the field of view can be completely clear.
Window		Using 5mm thick tempered glass
Window frame		Aluminum alloy door frame, ensure the safety and durability of the window
Windows Suspension Cable		Plastic suspension cable, low noise, fast pulling speed, strong balance characteristic
Control switch		LCD control panel, set with the power, switches, lighting, fan and running lights and other buttons, the LCD screen can clearly show the operation of the fume hood.
Socket		Equipped with four 220V universal socket. (Other type of socket can be optional, according to customers need)
Base cabinet		8.0mm PP polypropylene board, the door is firm solid, not easy to deformation, elegant appearance
Door handle		Laboratory PP handle, strong corrosion resistance.
Hinge		Laboratory PP hinge, strong corrosion resistance.
Water sink		PP cup , made of high-density PP ,strong corrosion resistance, with filtering and anti-odor function, water trap with high-density PP production( This is extra option)
Water cock		wall-mount remote control water valve, faucet, the main body is made of the thick copper, the surface with high brightness epoxy resin coating, corrosion resistance, heat resistance; Ceramic valve core, 90 ° rotation, life span 500,000 times, static maximum resistance Pressure 20 bar; switch knob for high-density PP production, ergonomic design, feel comfortable. (This is extra option)
Gas cock		Wall-mount remote control gas valve, the main body is made of the thick copper, the surface with high brightness epoxy resin coating, corrosion resistance, heat resistance; ergonomic design, feel comfortable. (This is extra option)



Exhaust system (Optional accessories)

Air Velocity /Exhaust air volume requiremen	0.4m/sec~0.6 m/sec.
Noise	≤60dB
Blower	PP centrifugal energy-saving fan, fan motor 380V three-phase motor, fan material PP polypropylene, with high strength, light weight, not easy to aging, low noise, excellent corrosion resistance and so on. (According to the actual need, equip with the fan, duct, etc., the fume hood price does not include the fan ,duct and related accessories prices.



Packing and Shipping:

Chemical Fume Hood Packaging and Shipping

• All packaging materials must be new and designed for the purpose of protecting the chemical fume hood.
• The chemical fume hood must be securely packed in a cardboard/wooden box or other suitable material.
• The box should be clearly labeled with the item name, serial number, and other relevant information.
• The box should be marked as “Fragile” or “Handle with Care”.
• The box should be sealed properly to ensure no movement of the package during transit.
• The chemical fume hood should be shipped in an upright position, to prevent any damage to the internal components.
